Description
Redway 36V 60Ah Lithium Iron Phosphate (LiFePO4) Battery is the latest in high voltage battery technology. Perfect for powering higher voltage motors, 36V or 72V 2~3 wheels e-scooters, e-rickshaw, and robotics applications – this small and compact battery provides an optimal solution with complete internal cell balancing, integrated protective circuitry and no EMI/RFI or noise.
36V 60AH LiFePO4 battery is perfect for 36V Marine Trolling Motors, 36V Golf Carts, Floor clean maching, e-forklifts, Sightseeing Car, RV, Boat, UPS, Solar ESS, and Robotics 36V system.
This battery has more power than 3 Lead Acid/AGM batteries rated at ~12V +120AH, offering also 10x lifetime than the Lead Acid/AGM batteries.
Put together in Parallel 3 x 36V60Ah and you have a 36V 180Ah system that is more powerful than any 36V 360Ah system in Lead-acid batteries.
36V 60Ah LFP Lithium Battery Specifications:
| Specifications | |
|---|---|
| Lithium Cell | LiFePO4 (LFP) |
| Nominal Voltage | 38.4V |
| Nominal Capacity | 60Ah |
| Nominal Energy | 2304Wh |
| Max Charge Voltage | 43.8V |
| Discharge Cut-off Voltage | 30V |
| Max Continues Charge Current | 100A |
| Max Continues Discharge Current | 100A |
| Dimensions [L x W x H] |
501 x 185 x 242 mm 19.7 x 7.3 x 9.5 inches |
| Weight | 15 kg 33 lbs |
| IP Rating | IP65 |
| Max Parallel Connections | 6 |
| Cycle Life | >5000 cycles (80% DOD 0.5C) |
| Self-Discharge | 3% (per month) |
| Charge Temperature | 0°C ~ 60°C |
| Discharge Temperature | -20°C ~ 65°C |
| BMS | JBD / DALY BMS Protection |
| Optional Upgrades | Self-heating / Bluetooth / App / 4G / GPS / WiFi / RS485 / RJ45 / SOC LCD Display / Circuit Breaker / Power Switch / Cooling Fan / Battery Internal Cell Fixation Metal Bracket / Active Balance / Solar MPPT / etc. |
| Normal Charger / Fast Charger | Optional |
| Terminal | M8 |
| Battery Shell | ABS |
| Design Life | 10 Years |
| Warranty | 3 Years |
| Label / Silkscreen / Laser Logo | Yes |
| User Manual | Yes |
| OEM | Yes |
| Shipment | Yes |
| Certifications | UL 1642 / IEC 62619 / CE / UN38.3 / MSDS |
