Specifications
| PM-LV51200-5U | |
|---|---|
| Lithium Cell Type | LiFePO4 |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Energy | 10.24kWh |
| Max Charge Voltage | 58.4V |
| Max Discharge Cut-off Voltage | 40V |
| Dimensions (L x W x H) | 570 x 440 x 222 mm 22.4 x 17.3 x 8.7 inches 5U |
| Weight | ~79kg ~174 lbs |
| Max Continuous Charge Current | 100A |
| Max Continuous Discharge Current | 100A |
| Charge Temperature | 0~60°C |
| Discharge Temperature | -20~60°C |
| Max Parallel Connections | 16 |
| Communications | RS485 / CAN-bus |
| Design Life | 20 Years |
| Cycle Life | >8000 Cycles (80% DOD 0.5C) |
| IP Rating | IP21 |
| Terminal | M6 |
| Battery Shell | Metal (Black, Gray, White, Blue, Green, etc.) |
| BMS | JBD BMS |
| Circuit Breaker | Yes |
| LCD Display | Yes |
| Optional Upgrades | SNMP, Bluetooth, App, WiFi, 4G, GPS, RS232, Self-heating, Power Switch, etc. |
| Compatible Inverters | Deye, Victron, GOODWE, Sol-Ark, SRNE, Solis, SAJ, Growatt, Luxpower, Voltronic, SMA, FOX, etc. |
| Certifications | UL 1642, UL 1973, IEC 62619, IEC 62133, CE, RoHS, UN38.3, MSDS |
